Crown Gear (Ash Ring Assembly) Pelco 1520 Boiler
Replacement Crown Gear for Pelco 1520 Biomass & Coal Boilers. The crown is apart of the ash ring assembly for Pelco Boilers.



Alternative Views:
Our Price: $150.00


Availability:: Usually Ships in 1 to 2 Weeks
Product Code: 804512
Qty:

Description

Crown Gear , Pelco 1520 (Painted)
for Pelco 1520 Biomass and Coal Boilers
Note: QTY of (2) is required.

This is the Replacement Crown Gear for the Complete Ash Ring Assembly for Pelco 1520 Coal Boilers. Original OEM part number:
804512
The Complete Ash Ring Assembly for the Pelco 1520 Boiler Includes the following parts:

1) P/N 806108 - Crown (qty 2)

2) P/N 804744 - Coal Retainer (qty 2)

3) P/N 804512- Crown Gear (qty 6)

4) P/N 804949 - Ash Shovel (qty 4)

5) P/N 804762 - Stir Finger (Optional) (qty 2)

6) P/N 804575 - Ash Ring Assembly (qty 1)

The Complete Pelco Ash Ring Assembly can be purchased on our website, by clicking link above.

Replacement Crown Gear for Pelco Biomass and Coal Boilers. See complete parts breakdown to confirm the exact parts needed for your ash ring assembly. Profab Company who manufactured Pelco boilers has gone out of business, voiding all warranty on existing boilers. Replacement parts are available through Obadiah's. If you do not see the part you are looking for parts that are not on our website, we might still be able to source it for you. If you do not see the part you are looking for, please call the office (406) 300-1776 with your model, serial number, date manufactured, and the part number or part description of the item you are looking for.
